PS6 RACK TRAY & POWER SUPPLY

The PS6 Rack Tray and Power Supply can house and power up to six of our CA series modules. It’s comprised of a 7U Rack Tray and a seperate 2U power supply. The 'soft-start'/standby feature allows you to switch the Filament and B+ voltages on and off separately.

Modules Available

Coil Audio CA-286

Coil Audio CA-70

PS6 Rack Tray

  • 7U 16 ga. Stainless Steel Rack Tray and Separate 2U Power Supply.
  • Rack Tray Provides Housing and Power for up to 6 MK2 PS6 modules.
  • 4’ Power Umbilical Cable with military-grade 5 Pin Amphenol Power
    Connectors.
  • Internal Point to Point Wiring with easily serviced Parts.
  • Filament supply 6.3v @ 4amps, regulated b+ 275v supply @ .5amps.
  • Switched filament power regulation for 1-3 or 4-6 modules installed.
  • “Fault light” illuminating Fuse holders.
  • PSU is factory wired for 115VAC or 230/240VAC mains (not user switchable)
  • Includes 6” IEC cable.
  • Weight: Rack Tray 16.5lbs (7.5kg) Power Supply 9.6lbs (4.35kg)
  • Dimensions: Rack Tray 19” W x 12”H x 8.25” D (482mm x 305mm x 209mm)
  • Power Supply 19” W x 3.25”H x 9” D (482mm x 82mm x 229mm)
  • Hand built and tested in the USA.
